QNAP TS-h686, NAS, Tower, Intel® Xeon® D, D-1602, 8 GB, DDR4
QNAP TS-h686. Type: NAS. Chassis type: Tower. Device class: Large Enterprise Business. Processor family: Intel® Xeon® D, Processor model: D-1602, Processor frequency: 2.5 GHz. Internal memory: 8 GB, Internal memory type: DDR4. Total installed storage capacity: 0 TB. Operating system installed: QuTS hero
| Storage | |
|---|---|
| Storage drive capacity | 0 |
| Supported storage drive interfaces | Serial ATA II, Serial ATA III |
| Storage drive sizes supported | 2.5,3.5 |
| Number of M.2 (M & B) slots | 2 |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10, 50, 60, JBOD |
| Online RAID migration | Yes |
| Online RAID expansion | Yes |
| RAID rebuild | Yes |
| Hot-swap drive bays | Yes |
| Supported file systems | FAT32, HFS+, NTFS, ZFS, ext3, ext4 |
| Storage drives installed | No |
| Total installed storage capacity | 0 |
| Number of storage drives supported | 6 |
| Installed storage drive type | No |
| Supported storage drive types | HDD & SSD |
| Bad block scan | Yes |
| Disk roaming | Yes |
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® D |
| Processor model | D-1602 |
| Processor frequency | 2.5 |
| Processor boost frequency | 3.2 |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor cache | 3 |
| CPU configuration (max) | 1 |
| PCI Express slots version | 2.0, 3.0 |
| Processor lithography | 14 |
| Processor operating modes | 64-bit |
| Processor package size | 37.5 x 37.5 |
| Scalability | 1S |
| Tcase | 84 |
| Tjunction | 105 |
| Thermal Design Power (TDP) | 27 |
| On-board graphics card model | Not available |
| Maximum internal memory supported by processor | 128 |
| Memory | |
| Internal memory | 8 |
| Internal memory type | DDR4 |
| Maximum RAM supported | 128 |
| Memory slots | 4 |
| Memory form factor | UDIMM |
| Flash memory | 5000 |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000,2500 |
| DHCP client | Yes |
| DHCP server | Yes |
| Jumbo frames support | Yes |
| iSCSI support | Yes |
| Wake-on-LAN ready | Yes |
| Supported network protocols | IPv4, IPv6 |
| Dynamic DNS (DDNS) | Yes |
| WLAN adapter supported | Yes |
| Ports & interfaces | |
| USB port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 4 |
| Concurrent connections | 10000 |
| PCI Express x8 (Gen 3.x) slots | 2 |
| Design | |
| Chassis type | Tower |
| Cooling type | Active |
| Product colour | Black |
| Number of fans | 2 |
| Fan diameter | 9 |
| Fan diameter 2 | 9.7 |
| LED indicators | HDD, LAN, SSD, Status, USB |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Performance | |
| Type | NAS |
| Device class | Large Enterprise Business |
| Backup function | Yes |
| Backup features | Cloud, iSCSI LUN |
| Buzzer | Yes |
| Multilingual support | Yes |
| Noise level | 18.6 |
| Snapshot | Yes |
| Web-based management | Yes |
| Security algorithms | 256-bit AES, AES, FIPS 140-2, HTTPS, SSH, SSL/TLS |
| Access Control List (ACL) | Yes |
| Reset button | Yes |
| On/off switch | Yes |
| Built-in FTP server | Yes |
| Browser supported | Apple Safari, Google Chrome, Microsoft Internet Explorer, Mozilla Firefox |
| System log | Yes |
| Hot spare | Yes |
| S.M.A.R.T. support | Yes |
| Share folder | CIFS/SMB |
| Universal Plug and Play (UPnP) | Yes |
| USB copy function | Yes |
| Software | |
| Operating system installed | QuTS hero |
| Operating system version | 10000 |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 |
| Linux operating systems supported | CentOS 7.0, SuSE Linux 12.0, SuSE Linux 12.3, SuSE Linux 15, Ubuntu 14.04, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04, Ubuntu 16.10, Ubuntu 17.10, Ubuntu 18.04 LTS, Ubuntu 20.04 LTS |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Other operating systems supported | IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 11 |
| Power | |
| Power supply location | Built-in |
| Power supply unit (PSU) capacity | 250 |
| Number of power supply units | 1 |
| Power consumption (typical) | 61.115 |
| AC input voltage | 100 - 240 |
| Fan voltage | 12 |
| Weight & dimensions | |
| Width | 224.9 |
| Depth | 319.8 |
| Height | 231.9 |
| Weight | 7.27 |
| Package weight | 8.72 |
| Packaging content | |
| Cables included | AC, LAN (RJ-45) |
| Power cables quantity | 1 |
| Quick installation guide | Yes |
| Number of screws | 24 |
| Drive tray key included | Yes |
| Processor special features | |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel QuickAssist Technology | No |
| Intel Trusted Execution Technology | Yes |
| Intel TSX-NI | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Maximum number of PCI Express lanes | 32 |
| Thermal Monitoring Technologies | Yes |
| Memory types supported by processor | DDR3-SDRAM, DDR4-SDRAM |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 35 |
| Operating relative humidity (H-H) | 5 - 95 |
| Storage temperature (T-T) | -20 - 70 |
| Storage relative humidity (H-H) | 5 - 95 |
| Logistics data | |
| Harmonized System (HS) code | 84714100 |
| Other features | |
| Fibre Channel | Yes |
| Processor ARK ID | 193686 |
Specifications
| Brand | QNAP |
