QNAP TS-653D, NAS, Tower, Intel® Celeron®, J4125, 8 GB, DDR4
QNAP TS-653D. Type: NAS. Chassis type: Tower. Device class: Small & Medium Business. Processor family: Intel® Celeron®, Processor model: J4125, Processor frequency: 2 GHz. Internal memory: 8 GB, Internal memory type: DDR4. Total installed storage capacity: 0 TB. Operating system installed: QNAP Turbo System
| Storage | |
|---|---|
| Storage drive capacity | 0 |
| Supported storage drive interfaces | Serial ATA II, Serial ATA III |
| Storage drive sizes supported | 2.5,3.5 |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Online RAID migration | Yes |
| Online RAID expansion | Yes |
| RAID rebuild | Yes |
| Hot-swap drive bays | Yes |
| Supported file systems | FAT32, HFS+, NTFS, ext3, ext4 |
| Storage drives installed | No |
| Total installed storage capacity | 0 |
| Number of storage drives supported | 6 |
| Installed storage drive type | No |
| Supported storage drive types | HDD & SSD |
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel® Celeron® |
| Processor model | J4125 |
| Processor frequency | 2 |
| Processor boost frequency | 2.7 |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor cache | 4 |
| CPU configuration (max) | 1 |
| PCI Express configurations | 1x4+1x2, 4x1, 2x1+1x2+1x2 |
| PCI Express slots version | 2.0 |
| Processor codename | Gemini Lake Refresh |
| Processor lithography | 14 |
| Processor operating modes | 64-bit |
| Processor package size | 25 x 24 |
| Processor socket | BGA 1090 |
| Tjunction | 105 |
| Thermal Design Power (TDP) | 10 |
| On-board graphics card model | Intel® UHD Graphics 600 |
| Maximum internal memory supported by processor | 8 |
| Memory | |
| Internal memory | 8 |
| Internal memory type | DDR4 |
| Maximum RAM supported | 8 |
| Memory slots | 2 |
| Memory form factor | SO-DIMM |
| Flash memory | 4000 |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000,2500 |
| DHCP client | Yes |
| DHCP server | Yes |
| Jumbo frames support | Yes |
| iSCSI support | Yes |
| Wake-on-LAN ready | Yes |
| Supported network protocols | FTP, SFTP, TFTP, PPTP, L2TP/IPSec, OpenVPN, QBelt |
| Link aggregation | Yes |
| Load balancing system | Yes |
| Dynamic DNS (DDNS) | Yes |
| WLAN adapter supported | Yes |
| Ports & interfaces | |
| USB port | Yes |
| USB 2.0 ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Ethernet LAN (RJ-45) ports | 2 |
| Graphics | |
| On-board graphics card base frequency | 250 |
| On-board graphics card burst frequency | 750 |
| On-board graphics card dynamic frequency (max) | 750 |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.4 |
| On-board graphics card ID | 0x3185 |
| Maximum on-board graphics card memory | 8 |
| Number of displays supported (on-board graphics) | 3 |
| Design | |
| Chassis type | Tower |
| Cooling type | Active |
| Product colour | Black |
| Number of fans | 2 |
| Fan diameter | 9 |
| LED indicators | HDD, LAN, Power, Status, USB |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Performance | |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Yes |
| Backup features | Cloud, USB drive, iSCSI LUN |
| Buzzer | Yes |
| Multilingual support | Yes |
| Noise level | 21.3 |
| Third-party support | Yes |
| Web-based management | Yes |
| Security algorithms | 256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS |
| Access Control List (ACL) | Yes |
| Reset button | Yes |
| On/off switch | Yes |
| Built-in FTP server | Yes |
| Browser supported | Apple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox |
| System log | Yes |
| Hot spare | Yes |
| S.M.A.R.T. support | Yes |
| Share folder | CIFS/SMB, FTP, WebDAV |
| Remotely operated | Yes |
| Backup button | Yes |
| Universal Plug and Play (UPnP) | Yes |
| USB copy function | Yes |
| Software | |
| Operating system installed | QNAP Turbo System |
| Operating system version | 5.0.0 |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Power | |
| Power supply location | External |
| Power supply unit (PSU) capacity | 120 |
| Number of power supply units | 1 |
| Redundant power supply (RPS) support | No |
| Power consumption (typical) | 35.437 |
| Power consumption (sleep) | 18.634 |
| AC input voltage | 100 - 240 |
| Fan voltage | 12 |
| Weight & dimensions | |
| Width | 235 |
| Depth | 226 |
| Height | 168 |
| Weight | 2.87 |
| Package weight | 4.56 |
| Packaging content | |
| External power adapter | Yes |
| Cables included | AC, LAN (RJ-45) |
| Power cables quantity | 1 |
| Processor special features | |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® OS Guard | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Secure Key | Yes |
| Intel® Smart Response Technology | No |
| Intel® Turbo Boost Technology | No |
| Maximum number of PCI Express lanes | 6 |
| Number of execution units | 12 |
| Thermal Monitoring Technologies | Yes |
| UART | Yes |
| Memory types supported by processor | DDR4-SDRAM, LPDDR4-SDRAM |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Operating relative humidity (H-H) | 5 - 95 |
| Storage temperature (T-T) | -20 - 70 |
| Logistics data | |
| Harmonized System (HS) code | 84714100 |
| Other features | |
| Processor ARK ID | 197305 |
