TP-Link TC85, IP security camera, Indoor & outdoor, Wireless, CE, FCC, DOE, CEC, RCM, KC, NCC, BSMI, NTRA, Ceiling/wall, White
TP-Link TC85. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wireless. Mounting type: Ceiling/wall, Product colour: White, Form factor: Bullet. Lens viewing angle, horizontal: 134°, Lens viewing angle, vertical: 77°, Lens viewing angle, diagonal: 150°. Sensor type: CMOS, Optical sensor size: 25.4 / 3 mm (1 / 3"). Fixed focal length: 2.1 mm
| Performance | |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wireless |
| Wide Dynamic Range (WDR) | Yes |
| Built-in light | Yes |
| Certification | CE, FCC, DOE, CEC, RCM, KC, NCC, BSMI, NTRA |
| Design | |
| Form factor | Bullet |
| Mounting type | Ceiling/wall |
| Product colour | White |
| LED indicators | Status |
| International Protection (IP) code | IP66 |
| Camera | |
| Lens viewing angle, horizontal | 134 |
| Lens viewing angle, vertical | 77 |
| Lens viewing angle, diagonal | 150 |
| Image sensor | |
| Optical sensor size | 25.4 / 3 |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Lens system | |
| Number of lenses | 1 |
| Maximum aperture number | 2.1 |
| Fixed focal length | 2.1 |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 15 |
| LED type | IR |
| Infra-red wavelength | 850 |
| Video | |
| Maximum resolution | 2560 x 1440 |
| Total megapixels | 4 |
| Video compression formats | H.264 |
| Frame rate | 15 |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Audio | |
| Built-in speaker(s) | Yes |
| Audio system | 2-way |
| Built-in microphone | Yes |
| Network | |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Storage | |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 512 |
| Security | |
| Built-in siren | Yes |
| Siren noise level | 94 |
| Video motion detection | Yes |
| Security algorithms | 128-bit AES, SSL/TLS, WPA, WPA2-PSK |
| Intelligent Video Surveillance (IVS) system features | Human detection, Pet detection, Vehicle detection |
| Management features | |
| Reset button | Yes |
| Remotely operated | Yes |
| Power | |
| Power source type | Battery, Solar |
| AC input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| DC output voltage | 5 |
| DC output current | 2 |
| Battery technology | Lithium-Ion (Li-Ion) |
| Standby time | 180 |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 45 |
| Storage temperature (T-T) | 10 - 90 |
| Operating relative humidity (H-H) | -20 - 60 |
| Storage relative humidity (H-H) | 5 - 90 |
| Weight & dimensions | |
| Diameter | 6.48 |
| Length | 116.2 |
| Packaging content | |
| Number of cameras | 1 |
| Cables included | USB |
| Mounting brackets included | Yes |
| Screws included | Yes |
Specifications
| Brand | TP-Link |
| Manufacturer | TP-Link |
