TP-Link VIGI C340S, IP security camera, Outdoor, Wired, 0.0005 lm, 120 dB, Wall
TP-Link VIGI C340S. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: White, Form factor: Bullet. Minimum illumination: 0.0005 lx, Lens viewing angle, horizontal: 95.2°, Lens viewing angle, vertical: 50.6°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Detect distance: 70 m, Observe distance: 29 m, Recognize distance: 14 m
| Performance | |
|---|---|
| Type | IP security camera |
| Placement supported | Outdoor |
| Connectivity technology | Wired |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Luminous flux | 0.0005 |
| Dynamic range | 120 |
| Design | |
| Form factor | Bullet |
| Mounting type | Wall |
| Product colour | White |
| Housing material | Metal, Plastic |
| International Protection (IP) code | IP67 |
| Camera | |
| Minimum illumination | 0.0005 |
| Lens viewing angle, horizontal | 95.2 |
| Lens viewing angle, vertical | 50.6 |
| Lens viewing angle, diagonal | 114.7 |
| Tilt angle range | -90 - 90 |
| Pan range | -90 - 90 |
| Camera shutter speed | 1/10000 |
| Number of Privacy masking areas | 4 |
| Image sensor | |
| Optical sensor size | 25.4 / 1.8 |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Lens system | |
| Number of lenses | 1 |
| Detect distance | 70 |
| Observe distance | 29 |
| Recognize distance | 14 |
| Focal length range | 4 |
| Maximum aperture number | 1 |
| Identify distance | 7 |
| Minimum aperture number | 1 |
| Fixed focal length | 4 |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 30 |
| LED type | White |
| Number of illumination LEDs | 4 |
| Video | |
| Maximum resolution | 2688 x 1520 |
| Total megapixels | 4 |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2550 x 1440, 2688 x 1520 |
| Frame rate | 60 |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Privacy masking | Yes |
| Bit rate | 4 Mbps |
| Region of Interest (ROI) encoding | Yes |
| Audio | |
| Built-in speaker(s) | Yes |
| Sample rate | 8 |
| Signal-to-Noise Ratio (SNR) | 52 |
| Built-in microphone | Yes |
| Bit rate range | 64 - 64 |
| Network | |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
| Password protection | Yes |
| IP address filtering | Yes |
| Privacy protection | Yes |
| Digest authentication | Yes |
| Power | |
| Power source type | DC |
| Power consumption (max) | 10.1 |
| DC output voltage | 12 |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 60 |
| Storage temperature (T-T) | -40 - 60 |
| Operating relative humidity (H-H) | 0 - 95 |
| Storage relative humidity (H-H) | 0 - 95 |
| Weight & dimensions | |
| Width | 102 |
| Depth | 236 |
| Height | 99 |
| Packaging content | |
| Number of cameras | 1 |
Specifications
| Brand | TP-Link |
| Manufacturer | TP-Link |
